Description
- Field adjustable power switch to select between 18W, 28W, and 44W outputs.
- Comes with a field-adjustable CCT switch inside the fixture that allows you to choose between 3500K, 4000K, and 5000K color temperatures.
- Includes mounting hardware, cordgrip, and hole plug for out-of-the-box installation.
- Long-life, high-efficacy LEDs with a 100,000 life hour rating.
- Excellent replacement for 3-lamp 32 Watt (T8) fluorescent fixtures.
- 5-year, limited manufacturer warranty.
With robust construction, flexible outputs, and unmatched versatility, our vapor tights can effortlessly stand up to the toughest conditions. They come in standard and medium-width body options in a variety of sizes, and have an IP66 rating – ensuring that moisture and dust don’t get in – and top-level IK10 impact resistance. That’s Light Made Easy®, even at the toughest time. With one manufacturer behind both driver and fixture, you don’t have to worry about compatibility, ensuring superior performance.
Adjust the wattage of the fixture to optimize maximum brightness. Select between 18 watt, 28 watt, and 44 watt settings. Can be dimmed down for further control with 0-10V dimming.
Change the look and feel of your fixture by switching the color temperature. Each fixture comes with a switch that selects between 3500K neutral white, 4000K cool white, and 5000K daylight color temperatures.
The IP66 rating ensures moisture and dust don’t get in, and are ETL Sanitation Listed NSF/ANSI Standard 2 – Food Equipment, Splash Zone (Not for Direct Food Zone), so they can be used in a variety of demanding environments and can handle high-pressure washdowns.
Our vapor tights include durable, stainless steel lens clips, an impact-resistant polycarbonate lens, and an IK10 impact resistance rating. The NEMA 4X rating assures resistance against corrosion. Even the adjustable hanging brackets and high-quality clasps are constructed for long life.
Listings & Certifications
UL
IP66
NSF
DLC
Warranty Information
Keystone Technologies, LLC., P.O. Box 246, Ambler, PA 19002, (215) 283-2600 (hereinafter called “Keystone Technologies”) warrants to the purchaser of its LED fixtures, retrofit kits, and light engines (hereinafter called “lighting components”) to be free of defects in material and workmanship and comply with their respective published specifications, from the date of installation, for time periods outlined below and subject to the terms and conditions herein. This warranty applies to fixtures that are operated within usage limit, 8,760 hours per year for a total of 5 years. If fixtures fail to operate for the warranty period, Keystone will, at its sole discretion, provide a free replacement fixture (but no labor allowance) or issue a credit for future purchase. This warranty is not applicable if the lighting component is not installed in accordance with the National Electric Code, the Standards for Safety of Underwriters Laboratories, Inc., Standards for the American National Standards Institute, or the Canadian Standards Association. This warranty is also not applicable if the lighting component is not installed according to Keystone Technologies instructions or recommendations or if the product has been exposed to abnormal operating conditions including excessive temperatures. For more information please go to www.keystonetech.com
View AllClose
Additional Information
Manufacturer: |
Keystone Technologies |
Brand / Product Series: |
Keystone |
MPN: |
KT-VTLED44PS-4A-8CSA-VDIM |
Model: |
KT-VTLED44PS-4A-8CSA-VDIM |
Wattage: |
18/28/44 Watt |
Equivalent: |
(3) F32T8 |
Lumens: |
2,592-5,852 |
Efficacy: |
131-144 lumens / Watt |
Color Temperature (CCT): |
3500/4000/5000 Kelvin |
Life Rating: |
100,000 Hours |
CRI: |
80+ |
Voltage: |
120/208/240/277 |
Frequency: |
N/A |
Power Factor: |
>0.95 |
THD: |
<20% |
Surge Protection: |
N/A |
Dimmable: |
Yes, 0-10V |
Options: |
Standard |
Mounting: |
Surface / Suspension |
Housing Material: |
Plastic |
Finish: |
Gray |
Lens Material: |
Polycarbonate |
IP Rating: |
IP66 |
Location Rating: |
Wet |
Length: |
47.25 in. |
Width: |
3.54 in. |
Height: |
2 in. |
Weight: |
N/A |
UL: |
Yes |
ETL: |
Yes |
RoHS: |
No |
NSF: |
Yes |
Energy Star: |
No |
FCC: |
N/A |
DLC: |
Yes |
DLC ID: |
PEMNI17A |
Warranty: |
5-Year Manufacturer |
