Description
- Comes with a field-adjustable CCT switch inside the fixture that allows you to choose between 2700K, 3000K, 3500K, 4000K, and 5000K color temperatures.
- Excellent replacement for 60 watt incandescent fixtures.
- Universal input voltage, 120-270V.
- Low profile design and remote driver enclosure ideal for shallow plenums.
- Spring loaded universal mounting clips ensure secure fit to ceiling.
- Long-life, high-efficacy LEDs with a 50,000 life hour rating.
- Dimmable down to 10% on compatible TRIAC/ELV systems.
- 5-year, limited manufacturer warranty.
Designed for maximum flexibility, the WFRX family lets you change color temperature and wattage with the flick of a switch! Available in 4” and 6” models, they’re ideal for new construction and retrofit applications. Rated for use in dry, damp, and wet locations, the WFRX is perfect for any application you throw at it, whether indoor or outdoor. The Lightcloud Blue XDIM family of dimmers makes it easy to install with any TRIAC/ELV or 0-10V dimmable fixture. Quickly pair to your phone to enjoy wireless control — no hub required. Add the Nano to use voice commands and control your lights from anywhere.
Adjust the wattage of the fixture to optimize maximum brightness. Select between 8 watt, 10 watt, and 12 watt settings. Can be dimmed down for further control with 120V dimming.
Change the look and feel of your fixture by switching the color temperature. Each fixture comes with a switch that selects between 2700K warm white, 3000K soft white, 3500K neutral white, 4000K cool white, and 5000K daylight color temperatures.
Installations are super flexible with an off-board driver that minimizes installation height, maximizes thermal management, and eliminates the need for a traditional recessed housing or "can". A plenum-rated cable connector links the downlight module to the remote driver, and then the module snaps into place with the adjustable, spring-loaded retention clips.
The wafer's spring-loaded clips are adjustable and designed to be used with various drywall thicknesses. Their long length makes them easy to install, and their heavy-duty design makes sure they stay in place. Wafers even include a large flange to compensate for holes that are cut incorrectly.
Listings & Certifications
UL
Energy Star
RoHS
NEC
Title 24
Warranty Information
The RAB 5-year, no-compromise warranty covers light output, color stability, driver performance, paint finish and labor. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
View AllClose
Additional Information
Manufacturer: |
RAB Lighting |
Brand / Product Series: |
RAB |
MPN: |
WFRX-4D |
Model: |
WFRX-4D |
Wattage: |
8/10/12 Watt |
Equivalent: |
75 Watt |
Lumens: |
675-1,100 |
Efficacy: |
83-92 lumens / Watt |
Color Temperature (CCT): |
2700/3000/3500/4000/5000 Kelvin |
Beam: |
110° |
Life Rating: |
50,000 Hours |
CRI: |
90+ |
Size: |
4 inch |
Voltage: |
120/208/240/277 |
Frequency: |
60 Hz |
Power Factor: |
>0.90 |
Dimmable: |
Yes, 120V |
Connection: |
Remote Junction Box |
Shape: |
Round |
Adjustable: |
No |
Housing Material: |
Plastic |
Finish: |
White |
Lens Material: |
Polycarbonate |
Trim Color: |
White |
Trim Design: |
Smooth |
IP Rating: |
N/A |
Location Rating: |
Wet |
Mounting: |
Spring Clips |
Length: |
4.75 in. |
Width: |
4.75 in. |
Height: |
0.5 in. |
UL: |
Yes |
ETL: |
No |
RoHS: |
Yes |
Energy Star: |
Yes |
Fire Rated: |
No |
FCC: |
Yes |
Air Tight: |
Yes |
NEC: |
Yes |
IC: |
Yes |
Title 20: |
N/A |
Title 24: |
Yes |
DLC: |
No |
DLC ID: |
N/A |
Warranty: |
5-Year Manufacturer |
