Description
- Field adjustable power switch to select between 100W, 130W, and 160W outputs.
- Comes with a field-adjustable CCT switch that allows you to choose between 3500K, 4000K, and 5000K color temperatures.
- Choose from 55°, 85°, or 105° to control where the light gets spreads.
- Fixture comes with a v-hook for chain mounting.
- Compact low-profile design only 2.94" in height.
- Long-life, high-efficacy LEDs with a 100,000 life hour rating.
- Excellent replacement for 4-lamp (T5HO) fluorescent, 6-lamp (T8) fluorescent, or 400 Watt HID fixtures.
- 5-year, limited manufacturer warranty.
The RBAY22 puts you in control with adjustable optics that let you customize light distribution to match your space. Choose from three beam angles (55°/85°/105°) to get light exactly where you need it—whether it's serving as a long, narrow-beam aisle lighter or as general, wide-throw coverage. Field-selectable wattage and CCT let you fine tune that performance!
Adjust the wattage of the fixture to optimize maximum brightness. Select between 100 watt, 130 watt, and 160 watt settings. Can be dimmed down for further control with 0-10V dimming.
Change the look and feel of your fixture by switching the color temperature. Each fixture comes with a switch that selects between 3500K neutral white, 4000K cool white, and 5000K daylight color temperatures.
All models of the RBAY22 include adjustable light beam angles. Choose from 55°, 85°, or 105° to select between medium, wide, and very wide flood spreads. Defaulted to 85°.
The RBAY22 is engineered for durability and longevity. Its precision die-cast aluminum housing and frosted polycarbonate lens provide superior protection, while an operating that tops out at 122°F guarantees that this fixture will thrive in demanding environments.
Listings & Certifications
UL
RoHS
IP66
DLC
Warranty Information
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
View AllClose
Additional Information
Manufacturer: |
RAB Lighting |
Brand / Product Series: |
RAB |
MPN: |
RBAY22S |
Model: |
RBAY22S |
Wattage: |
100/130/160 Watt |
Equivalent: |
4-lamp (T5HO) / 6-lamp (T8) / 400 Watt Metal Halide |
Lumens: |
14,460-23,22 |
Efficacy: |
133-163 lumens / Watt |
Color Temperature (CCT): |
3500/4000/5000 Kelvin |
Life Rating: |
100,000 Hours |
CRI: |
80+ |
Voltage: |
120/208/240/277 |
Frequency: |
50/60 Hz |
Power Factor: |
>0.90 |
THD: |
<10% |
Surge Protection: |
6kV + 6kV |
Dimmable: |
Yes, 0-10V |
Options: |
Standard |
Mounting: |
V-Hook |
Housing Material: |
Aluminum |
Finish: |
White |
Lens Material: |
Polycarbonate |
IP Rating: |
IP66 |
Location Rating: |
Wet |
Length: |
16.56 in. |
Width: |
12.38 in. |
Height: |
2.94 in. |
Weight: |
8.8 lbs |
UL: |
Yes |
ETL: |
No |
RoHS: |
Yes |
Energy Star: |
No |
FCC: |
N/A |
DLC: |
Yes |
DLC ID: |
S-BKXYSB |
Warranty: |
5-Year Manufacturer |
