Description
Available in four sizes, the H17 series offers three selectable lumen outputs and three CCTs, making it versatile enough to handle countless applications. The H17SB includes an expansion port that makes it easy to add a PIR or microwave sensor. Both can be configured to adjust brightness and hold time, saving additional energy and costs. A remote is also available for yet another added level of control. The H17SB high bay is incredibly compact (small model is less than a foot in diameter) but delivers incredibly high output, replacing up to 350W MH, and boasts ultra-high efficacy...all at an affordable price.
Key Features
- Replacement for traditional Metal Halide or Linear Fluorescent high bay fixture
- Color temperature selectable: 3000K, 4000K or 5000K
- Wattage adjustable: 60 watt, 80 watt, 100 watt
- 100,000 hour lifespan rating
- DLC Premium Listed
- Suitable for wet locations, IP65 rated
- Rated for use in ambient temperatures up to 145°F
- Built in 6kV surge protection
- Dimmable down to 10% with 0-10V standards
- Backed by a 5-year warranty
Specifications
| SKU | 22011 |
| Manufacturer | RAB Lighting |
| Brand | RAB |
| Manufacturer Part No. | H17SB |
| Model | H17SB |
| UPC | N/A |
| Fixture Type | Round High Bay |
| Light Technology | LED |
| Wattage | 60, 80, or 100 Watt |
| Equivalent | 200-350W Metal Halide |
| Life Hours | 100,000 Hours |
| Color Rendering (CRI) | 80+ |
| Lumens | 14959 |
| Efficacy (LPW) | 169 |
| Color Temperature (CCT) | 3000K, 4000K or 5000K |
| Voltage | 120/208/240/277 V |
| Frequency | 50/60 Hz |
| Power Factor | >0.90 |
| THD | <10% |
| Surge Protection | 6kV |
| Dimmable | Yes |
| Dimming Type | 0-10 V |
| Housing | Aluminum |
| Mounting | 3/4"-14 NPT Hook |
| Lens | Polycarbonate |
| Finish | White |
| Operation Temperature | -40°F to 145°F |
| Length | 10.25 in. |
| Width | 10.25 in. |
| Height | 7.38 in. |
| Weight | 7.3 lbs. |
| DLC | Yes |
| DLC ID | S-15S3PM |
| Energy Star | No |
| Environment | Wet Locations |
| UL | Yes |
| ETL | No |
| IP Rating | IP65 |
| RoHS | Yes |
| Warranty | 5-Year |
Warranty Information
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
View AllClose
Additional Information
Wattage: |
60/80/100 W |
Lumens: |
14959 |
Lumens per Watt: |
169 |
Voltage: |
120/208/240/277 V |
Color Temperature (CCT): |
3000K, 4000K or 5000K |
CRI: |
80+ |
Dimmable: |
Yes |
Power Factor: |
>0.9 |
Mounting: |
3/4" NPT Hook |
Finish: |
Black |
Options: |
Standard |
